Telesis Technologies Introduces the NEW TMC600 Marking System Controller

Telesis Technologies Introduces the NEW TMC600 Marking System Controller

Product News Friday, November 14, 2014: Telesis Technologies, Inc.



COMPANY CONTACT

John Heinrich
Marketing Manager
Voice:  740-420-6527
Fax: 740-477-5001
John.Heinrich@telesistech.com

FOR IMMEDIATE RELEASE



Telesis Technologies Introduces the

NEW TMC600 Marking System Controller

TMC600 Marking System Controller TMC600 marking system controller runs the Merlin® Touch PS software and provides a touch screen user interface for operating the marking system. The controller features an integrated, 10-in., high-resolution, touch screen monitor in the top panel. The back panel of the controller provides the electrical interfaces for connecting to the marking system and optional, remote I/O sources.



The powerful Telesis Merlin®Touch PS software is a Windows® based software package that comes installed in the TMC600 controller. It is a graphical user interface that makes pattern design and marking quick and easy. The WYSIWYG (what-you-see-is-whatyou- get) interface provides a scale image of the pattern as it is created. The Merlin®Touch PS software includes tools to create and edit pattern files for marking. Each pattern can contain one or more fields; each field defines a single object. Printable objects may be created consisting of any combination of text strings, arc-text strings, geometric text strings, geometric shapes, graphics, and machine-readable data matrix symbols. Just “click and drag” for immediate adjustment to object size, location, or orientation.



Printable text fields may include alphanumeric characters, symbols, and special message flags. Message flags automatically insert data into the text string, such as serial numbers, times, dates and user-defined codes. Multiple fields may be grouped and saved as a block to form a logo. Existing DXF files can also be imported for marking. Non-printable fields can be created to clearly display a graphical representation of the part being marked. Commands may be defined.



CONTROLLER FEATURES:

  • Powerful Windows® 8.1 based OS
  • 10” Hi-Res Capacitive touch screen
  • Multiple integrated I/O ports including, TTL, opto-isolated, VGA, and 4 USB ports
  • Easy Networking capabilities with Ethernet port for TCP/IP communications
  • EtherNet/IP and PROFINET capable
  • Resident support of 2D, QR and GS1 codes
  • Additional axis control (rotary, Z axis, linear stages) via optional integrated driver board
