Konica Minolta Offers High-Quality Color Control Products For The Food Industry

Konica Minolta Offers High-Quality Color Control Products For The Food Industry

Product News Tuesday, August 28, 2012: Konica Minolta Sensing Americas


Two Principal Color Measurement Techniques
In current food industries’ practice, two principal color measurement techniques are used: Colorimetry and Spectropotometry.

Colorimetry is the technique which quantifies color by measuring three primary color components of light which are seen by the human eye, specifically, red, green and blue (also referred to as “RGB”).
This “tristimulus” color measurement provides data on how much of these three components are present in the light reflected (solids) or transmitted (typically liquids) by a food product. Such data may be used, for example, to adjust the color components in a prepared food or beverage recipe to improve “eye-appeal,” to gauge “doneness” in a baked product, and, in fresh foods, to determine factors such as degrees of ripeness and spoilage in relation to shipping,
storage, shelf-life, palatability and disposal cycles. Although there is no strict demarcation line where the benefits of colorimetry in foods ends, it should be recognized that it measures color much the same as the human eye. That is, secondary and tertiary colors such as orange, yellow, violet, tans, browns, etc. are not individually quantifiable. This leaves a variability factor which can hamper the consistent reproducibility of a desired color in prepared food products which are formulated for a specific, consistently produced look.

Spectrophotometry, a scientific “step up” so to speak, is presently the most precise and accurate technique for the measurement, formulation and quality control of desired colors in prepared food products. Spectrophotometer instruments measure the spectral reflectance or transmittance of an object across the full spectrum of human visible light wavelengths, 400 nm to 700 nm (nanometers), enabling precise specification of any desired color. Spectrophotometers offer greater specificity, making them the instruments of choice for food product color formulation, specification of standards and tolerances, inter-plant color communication and color quality control in processing operations.

Over the last decade, spectrophotometers have been increasingly adopted in the food industries for color standardization and QC inspection of ingredients prior to use, for specification of final product color (particularly in jams, jellies, preserves, beverages, etc.), in research and development of new food and beverage products, and in potential food screening and sorting techniques for factors ranging from carcass’s naturalfat content to quality grading of meats, poultry and fish.


Software and Methodologies
One indispensable, key factor in the food industries’ growing use of both colorimetry and spectrophotometry is the availability of easy to understand and easy to adapt Color Data Software for color measurement, color matching, color formulation and color quality control. When correlated with all other food laboratory and quality control data, color itself can become an integral clinical data component of
factors ranging from product appeal to shelf-life to possible spoilage and/or contamination risks. Color formulation software and color matching software packages are available with portable and bench-top spectrophotometers for use in laboratory color control systems. Color quality control software with sample pass/fail comparison testing and database update functions is a standard component of those systems, and is also an integral onboard QC inspection function of our Konica Minolta portable colorimeters and spectrophotometers.

The art in the science of integrating color as a food quality component lies in the methodology developed and used by food producers and the food processors. In the food sciences, technologies are developed in response to needs enunciated and defined by food industry scientists and technologists. At Konica Minolta Sensing, we view our role as being technologically responsive: that is, the food industries’ scientists and technologists foresee their color measurement and methodology goals and, in turn, we attempt to create and apply technologies to fulfill their needs. Over the last 20 years, we have moved through nearly four generations of technologies. The following examples give a view of the continuing advance of food color measurement, as well as hints of where it may go in the 21st Century.

A Flour by Any Other Name is Still?
One would think that in manufacturing regular white pasta flour, color wouldn’t be much of an issue. Well, with every kitchen becoming a home gourmet’s retreat, the surge in specialty flours and the homegrown sprouting of epicurean eyes and palates, which claim almost preternatural abilities to discern food ingredients, it’s now an issue - and one to be avoided.

This challenge was presented by a semolina flour manufacturer who wished to determine the best method for standardizing the color of the company’s semolina products, not just for consumer lines, but for commercial products, too. The problem was natural: semolina wheat grains vary in color. The manufacturer was already combining both grain and flour lots to average the color mixtures, but felt numerical
standards and tolerances were needed to assist operations in averaging the ingredients.

The solution was first standardizing an ideal semolina flour using a Konica Minolta Colorimeter System, and then measuring individual flour lots for their color characteristics. By sample averaging, color variability within each lot was reduced, and then computer color matching of lots for successful color mixture potential in a final flour blend became possible.

Fresh Mangos in Frozen Maine
In the 1990’s, TransFRESH Corporation, a leader in the development of modified and controlled atmosphere systems for the transport of perishable foods, initiated an advanced program to gauge the maturation and spoilage rates of specific fresh produce items. Creating a controlled atmosphere to keep produce fresh during shipment requires extensive testing. Since there is a direct correlation between the ripeness of various fruits and their color, TransFRESH initiated a program using a Konica Minolta colorimeter to chart the ripening process under various controlled atmospheric conditions over typical durations of shipment. For example, the measured color of an avocado rind provided data about its point of ripeness. Similarly, the rate of discoloration of the rind allowed plotting of the maturation process. Today,
TransFRESH can determine precisely the right atmosphere needed for a particular product shipment to arrive fresh at its retailer.

Surf, Turf and barnyard
Since the mid 1990s, Konica Minolta has been working with more and more operations in the seafood, meat and poultry industries worldwide to help them develop and improve color test and measurement methodologies for a broad range of factors. We have worked on a barge in the Pacific Northwest for a fisheries’ association to help them establish quality and nutritive content standards for Pacific Salmon using portable and bench top spectrophotometer systems to measure the pink flesh. Similarly in the North American beef industry, both colorimetry and spectrophotometry are being tested and used in various ways to classify the fat content of carcasses and cuts, both on and off processing lines, by quantifying the relative “marbling” of meat by precise reference to overall color. In the poultry industry, our portable spectrophotometers are now in wide use every day on processing lines where they measure the skin “yellowness” of carcasses to determine fat content.

From ice cream, yogurt and cheeses in the dairy section, to lunch meats, sausages and sauces, we are working with food technologists to help test and assure that their final product color has the “eye-appeal” needed for retail success. Since it is all about food, we really love the work and look forward to more challenges in the years ahead.
