Liquid particle counters, size measurement analysis instruments, systems and solutions are available for the broad categories of Water and Liquids, Air and Gaseous Media, and Oil.
Water, Oil and Liquid particle counters – for Medical, Pharmaceutical and Industrial applications – including oil calibration to ISO 4406 and NAS 1638.
Air and Gaseous Media particle counters – for Medical, Pharmaceutical and Industrial applications – including ISO 14644.
Particle Standards for instrument calibration and evaluation for resolution, precision and reproducibility - Independent - Certified.Water, Liquids & Oils
The “Abakus Mobile Fluid” particle counter is a portable particle counter for liquids, viscous media and oil. Using various sensors it has many applications. Controlling the cleanness of drinking water, chemical and pharmaceutical solutions, the performance of filtration facilities, checking viscous liquids and hydraulic oils are some examples. Particle size ranges from 0.9μm to 500 μm are possible. When used for oils these instruments can be calibrated to ISO4406 and NAS1638.
The “Syringe” particle measuring system has been developed for laboratory operations in the food, medical and pharmaceutical sectors. The unit is used, for example, for controlling cleanness of water, pharmaceutical solutions, chemicals and beverages. It may also be used to analyse particle sizes by suspension in liquids.
The PZG-3 / PZG-4 sample feeding systems, when configured with the “Abakus” particle counter and a PC measuring card, is an evaluation device for measuring particle numbers and sizes in liquids and very viscous media. The system covers a measuring range from 0.7 µm up to 1800 µm by the versatile use of a variety of sensors. It can be applied to controlling the cleanness of water, pharmaceutical solutions, chemicals, beverages and for analysing special suspensions. The PZG4 is also used for particulate counts in hydraulic, lubricating and transformer oils, and can be calibrated to ISO4406 and NAS1638.
The TCC - Three Channel Particle Counter - for In-line use with liquids is a control system for measuring the number and size of particles in liquids and gases. The liquid particle counter measuring system is designed for in line use. The device has a choice of sensors and the selected sensor is built into the Particle Counter measuring system depending on the application and customer’s requirement. The sensors are calibrated with certified latex particles. When used for oils these instruments can be calibrated to ISO 4406 and NAS 1638.Air and Gaseous Media
The “Abakus mobile air” particle counter is an evaluation system for measuring the number and size of particles in the air and in gaseous media to ISO14644. The measuring system is designed for both stationary and portable use. The devices cover a measurement range of 0.2 µm to 500 µm by the use of a choice of alternative particle sensors. This makes it appropriate for a variety of measurement applications:- monitoring of clean rooms, clean working benches, filter facilities in operating theatres, pharmaceutical filling operations and deposit concentrations on filters
The PPS air Particle Sensor is a pump sensor measuring system for particle concentration monitoring in clean rooms, production sites and industrial facilities. It is a stand-alone unit for operation in connection with an existing control, or for operation in a network. The integrated vacuum pump ensures a simple and cost-effective installation of the system.
The ATM 225 Aerosol Generator is designed to generate test aerosols with defined attributes. The concentration of aerosol particles is adjustable. A typical application for the aerosol generator is to test high-efficiency filters or the acceptance and control measurement of laminar flow boxes and clean rooms.
The FH-5 Impaktor is a measuring system for monitoring airborne bacteria content. The system is designed for both impaction and filtration methods. Typical applications are hospitals, pharmaceutical, cosmetic and food processing industries where low airborne bacteria concentrations are essential. Bacteria emissions from waste deposits, purification plants and irrigation applications are becoming increasingly important.Particle Standards
Particle size standards with certificates are designed for calibrating particle sizing instruments and for evaluating these devices regarding resolution, precision, reproducibility, etc. NIST and BCR traceable calibrants are used in the production of BS-Partikel products.Fluid Control
Fluid control maintains a long service life of fluids and components in hydraulic, lubrication and coolant systems. Investing in fluid power engineering achieves a long service life of fluids and components in hydraulic, lubrication and coolant systems. Fluid contr
