Tiny Voice Coil Actuator Packs a Punch

Tiny Voice Coil Actuator Packs a Punch

Product News Thursday, December 11, 2014: BEI Kimco

VISTA, Calif., − Dec. 11, 2014 –  BEI Kimco Magnetics announces the small, yet powerful model LAH04-10-000A Linear Voice Coil Actuator (VCA) as the latest addition to their extensive line of housed moving magnet actuators.   With this newest model in the line-up, BEI Kimco’s housed moving magnet actuator offering covers the size range from 0.375 inches to 2.4”  in outside diameter with a wide selection of stroke lengths, peak force, as well as full customization.

The new miniaturized device delivers a peak force of nearly 0.5 pounds and measures just 0.375 inches in outside diameter.  With a total weight of 0.37 ounces it produces over 20 times its own weight in terms of force  with an operating stroke of 4 mm (0.157”).  The tiny size and housed packaging allow for easy mounting in size critical applications.

The moving magnet design also offers excellent heat dissipation.  By allowing the magnet to move and keeping the coil fixed, any heat generated by the coil assembly can be readily conducted away.  No moving wires and a high heat dissipation makes this  new VCA particularly well-suited for high duty cycle applications such as pick and place machines, remotely controlled switching, medical and laboratory equipment, military and aerospace.

“This tiny packaged device opens up a whole new realm of possibilities for applications with extreme space limitations,” says Jim McNamara, BEI Kimco Senior Application Engineer.  “To our knowledge, it is the smallest diameter VCA on the market.  Housed actuators are becoming much more popular with our customers when compared to un-housed actuators.  Our continually expanding offering in wider size ranges supports this demand.”

BEI Kimco’s voice coil actuators feature all the inherent advantages of voice coil technology including direct-drive and hysteresis-free operation for highly accurate motion.  Other advantages of this technology include high acceleration, absence of commutation and excellent resolution.

For further information contact BEI Kimco Magnetics, Tel: (760) 597-7042; Toll-free: (800) 572-7560; Fax: (760) 597-6320; email:;


About BEI Kimco Magnetics

BEI Kimco Magnetics specializes in the design and manufacture of high performance rotary and linear motion components, including Brushless DC Motors and Voice Coil Actuators. These products are designed for applications where performance, precision, and reliability are critical. Using proprietary magnetic design methodologies, BEI Kimco Magnetics has the ability to produce custom, cost efficient products within multiple manufacturing locations.  BEI Kimco Magnetics is a leader in medical, industrial, aerospace & defense markets.

BEI Kimco Magnetics is a brand of Custom Sensors & Technologies (CST).


About CST

Custom Sensors & Technologies (CST) is a specialist in designing and manufacturing sensing, control and motion products.
Through its brands, BEI Kimco, BEI Sensors, BEI PSSC, Crouzet, Crydom, Kavlico, Newall and Systron Donner Inertial, CST offers customizable, reliable and efficient components for mission-critical systems in Aerospace & Defense, Transportation, Energy & Infrastructure, Medical, Food and Beverage and Building Equipment markets.

Focused on premium value offers and committed to excellence, CST, with 4.500 employees worldwide and sales of $600M US in 2013, is the dependable and adaptable partner for the most demanding customers.
